Product Description:
Equipped with a Female Pin connector, the Flexi-PCB ensures secure and reliable connections, enabling seamless integration within your electronic systems. Whether you are working on a complex industrial application or a sophisticated consumer electronics project, this Flexi-PCB with its Female Pin connector guarantees optimal performance.
Manufactured in the technology hub of Shenzhen, the Flexi-PCB embodies the quality and expertise synonymous with this renowned port. With state-of-the-art facilities and skilled professionals overseeing the production process, each Flexi-PCB is crafted to perfection, meeting the highest industry standards.
The Copper Thickness of the Flexi-PCB ranges from 0.5oz to 3oz, providing exceptional conductivity and signal integrity. This wide range of copper thickness options allows you to customize the Flexi-PCB based on your specific requirements, ensuring optimal performance and efficiency in your electronic designs.
One of the standout features of the Flexi-PCB is its waterproof design, offering protection against moisture and environmental factors. Whether used in outdoor applications or devices exposed to liquids, the waterproof feature of this Flexi-PCB ensures reliability and longevity, making it a versatile choice for various industries.
Rated for a current of up to 50V, the Flexi-PCB delivers consistent and stable power distribution, supporting the seamless operation of your electronic devices. With its high current rating, this Flexi-PCB is suitable for a wide range of applications, from low-power consumer electronics to high-performance industrial machinery.
Experience the flexibility and versatility of the Flexi-PCB, also known as the Flexi-Flex Board, as it empowers your innovative designs and enhances the connectivity of your electronic systems. Whether you are a seasoned engineer or a hobbyist maker, the Flexi-PCB is the perfect choice for your next project, offering reliability, performance, and quality in one advanced package.
Features:
-
Product Name: Flexi-PCB (Flexible Printed Circuit Board)
-
Min. Hole Size: 0.2mm
-
Max. Panel Size: 500mm X 500mm
-
Board Thickness: 0.2mm
-
Shape: Custom Design
-
Thickness: 0.1mm-0.3mm
Technical Parameters:
|
Min. Hole Size
|
0.2mm
|
|
Copper Thickness
|
0.5oz-3oz
|
|
Port
|
Shenzhen
|
|
Raw Material
|
Polyimide
|
|
Max. Operating Temperature
|
150°C
|
|
Rated Current
|
50V
|
|
Connector
|
Female Pin
|
|
Board Thickness
|
0.2mm
|
|
Features
|
Waterproof
|
|
Shape
|
Custom Design
|
Applications:
Flexible Printed Circuit Boards (Flexi-PCB) by tkm, originating from Dongguan China, are versatile electronic components suitable for a wide range of product application occasions and scenarios due to their unique features and specifications.
With a thickness ranging from 0.1mm to 0.3mm, tkm's Flexible PCBs are ideal for products requiring a slim and flexible design, such as wearable technology, smartphones, tablets, and other portable electronic devices.
The waterproof feature of these Flexi-PCBs makes them perfect for products used in outdoor or harsh environments, such as outdoor LED displays, automotive electronics, and marine equipment.
tkm's Flexible Printed Circuit Boards with a minimum hole size of 0.2mm are well-suited for compact electronic devices where space is limited, such as digital cameras, medical devices, and aerospace equipment.
Thanks to their custom design shape capability, Flexi-PCBs are ideal for products with non-traditional form factors or unique shapes, including curved displays, smart clothing, and IoT devices.
Furthermore, with a maximum operating temperature of 150°C, tkm's Flexible PCB Assembly is suitable for products that require high-temperature resistance, such as industrial control systems, automotive engine control units, and LED lighting applications.
