Medical Electric Key Switch Durable , Dustproof Membrane Touch Switch

TKM MEMBRANE TECHNOLOGY LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Medical Electric Key Switch Durable , Dustproof Membrane Touch Switch

Brand Name : TKM

Model Number : TKM-019

Certification : ISO9001:2008, SGS,Rohs

Place of Origin : China

MOQ : 100pcs

Price : negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000000Pieces per month

Delivery Time : 15-20days

Packaging Details : Polybag per pcs,50per cartoon

Overlay : F200

Circuit : Flexible Cable Circuit And Pins

Overlay color : Rich

Usage : Control Switch

Type : Flexible

Rear Adhesive : 3M467

Material : FPC/ PET/ PC

Technology : silk screen printing

Feature : key switch

Contact Now

The latest advanced medical electronic film key switch

Membrane Switch Performance Index:

1.Electronic characteristics

Circuit rating 35V (DC), 100mA, 1W
Contact resistance 10Ω~500Ω (According the trace length and materials)
Insulation resistance > 100MΩ 250V DC
Contact bounce ≤ 5ms
Dielectric withstand 250VRms (50~60Hz 1min)
Life expectancy flat type ≥ 5 million times, tactile type ≥ 1 million times

2.Mechanical Properties

Actuation force flat type: 57-284g (2-10 Oz), tactile type: 170~397g (6~14 Oz)
Switch stroke flat type: 0.1~0.5mm, tactile type: 0.6~1.5mm

3.Environmental parameters

Operating Temperature -40°C~+80°C
Storage temperature -40°C~+85°C
Humidity 40°C, 90% ~95%, 240 hours

Feature:

1.Light weight
2.small volume
3.long service life
4.Dampproof, dustproof
5.durable, seismic, lead wire resistance around thefracture well

Environmental


Storage Temperature: -40°C (-40°F) to +70°C (158°F).
Storage Altitude: Sea level to 35,000 feet.
Operating Temperature and Altitude: -30°C (-30°F) to +75°C (170°F). Can be
designed to operate in most environments.
Humidity: No delamination after 24 hours at 80°C and 90%RH.

Applications:

Products are widely used in communication, industrial control, household

appliances, GPS, children's kid-learning, electronic reading machine, various game machines, Instruments and Apparatuses, attendance machine,

Electronic scale, medical equipment, electronic tools equipment, automatic sewing machine,

Embroidery Machine, Machine Maintenance equipment, computer keyboard and electronic calculators and etc.

Remote control, control board for home appliances, medical equipment , auto, computer and cell phone, etc.

Both OEM and ODM orders are welcome.

Product show

Medical Electric Key Switch Durable , Dustproof Membrane Touch SwitchMedical Electric Key Switch Durable , Dustproof Membrane Touch Switch

Competitive Advantage:

1. Beautiful appearance,rich and bright in color,design can be arbitrary,the products can fully reflect the individual style of the product itself and designer.

2. Panel can wash,good protection of durable color,characters,logos and other panel contents without injury.

3. Small size,light weight ,thin thickness,good tactility,abrasion resistant,installation and connection convenience.

4. Tightness is good ,moisture-proof,dust-proof,waterproof,anti-oil,anti-corrosion and erosion of harmful gases proof,acid and alkali proof,quakeproof.

5. Low cost,high lifespan,membrane switch's design and manufacture are using the keyboard as a whole way,whether on the material or mold charges,the costs are lowest,the life expectancy of different types of membrane switch is more than 100million times.

6. Easy to operate,intuitive,safe and reliable,In-house 100% functionally tested,components are guaranteed without any intermittent problem.

7. Customized specification is available and keys can make different shapes

Workshop

Medical Electric Key Switch Durable , Dustproof Membrane Touch Switch

Our Services

1. OEM Order welcome: Product, Package...
2. Sample order Before mass production
3. We will reply you for your inquiry within 24 hours.
4. After sending sample, we will provide tracking number,when you got sample, test sample, if there's problem with the sample, please contact with us, we will solve problem at the first time.
